To facilitate the implementation of EtherCAT's technology, the development kit was developed by a team of hardware and software engineers with years of experience. Its design team has been researching, developing and commissioning EtherCAT related products since 2009, and has rich experience in product design. Compared with the development board, the after-sales support of the design team is the key to your purchase. We may be a useful guide to you, saving your energy, money, far more than the value of the development board.
|
EVB Name |
ESC |
MCU |
interface |
cycle |
sch |
soft |
|
ET1100-core |
ET1100 |
|
|
|
CORE |
|
|
ET1100-EVB-SPI |
ET1100 |
STM32F407 |
SPI |
1ms |
EVB |
STM32 MDK project |
|
ET1100-EVB-PB |
ET1100 |
STM32F407 |
asynchronous （16bit） |
125us |
EVB |
STM32 MDK project |
|
ET1100-EVB-DSP |
ET1100 |
DSP28335 |
SPI asynchronous （16bit） |
100us |
EVB |
DSP CCS5.5project SPI 并行两套 |
|
LAN9252-core |
LAN9252 |
|
|
|
CORE |
无 |
|
LAN9252-EVB-SPI |
LAN9252 |
STM32F407 |
SPI |
1ms |
EVB |
STM32 MDK project |
|
LAN9252-EVB-PB |
LAN9252 |
STM32F407 |
asynchronous （16bit） |
200us |
EVB |
STM32 MDK project |
|
LAN9252-EVB-DSP |
LAN9252 |
DSP28335 |
SPI asynchronous（16bit） （4bit addr CSR） |
125us |
EVB |
DSP CCS5.5 project SPI PB |
